Control Cables

Why opt for Sri Padmavathi Control Cables?

Sri Padmavathi Cables offer Control Cables in a wide range of variety. With 2 to 61 Core variants, the cross section area is customization between 1.5 to 2.5 sq mm. There are two types of conductors available; Solid Conductor & Stranded Conductor. The inner sheath consists of Extruded PVC (ST-1/ST-2 and the outer sheath is comprised of Extruded PVC /FR /FRLS/ LSZH.( ST-1/ST -2). Either Galvanized Steel Round Wire armoring or Flat Strip armoring is used in high density control cables.

Sri Padmavathi Cables follow stringent quality standards while manufacturing and the Control cables exceed the quality requirements as per IS 1554 Part-1, 1988, IS 7098 Part-1 1988, IEC 60502 & BS 5467.

2X: XLPE Insulation
W: Round Steel Wire
F: Flat Steel Strip Armoured
WW: Double Flat Steel Strip Armoured
WA: Non-Magnetic Aluminum Round Wire Armoured
FA: Non-Magnetic Aluminum Strip Armoured
Y: PVC Outer Sheath

We are provide a best offer for our stranded product for maximum and sizable order.

Padmavathi Cables is one of the best Control Cables manufacturer, Control Cables exporter, Control Cables supplier in Mumbai, India. We are serve this Control Cables in all over countries. If you want this products please quote Now

Technical Parameters

Number of Cores: 2 to 61 Core
Cross Section Area: 1.5 to 2.5 sq mm as per Specs.
Type of Conductor: Solid/ Stranded Copper
Class: 1 & 2 IS : 8130
Insulation: PVC/HR PVC/ XLPE IS: 5831, IS 7098 (P-1)
Inner Sheath: Extruded PVC (ST-1/ST-2)
Type of Armouring: Galvanized Steel Round Wire/Flat Strip
Outer Sheath: Extruded PVC /FR /FRLS/ LSZH.( ST-1/ST -2)
Application: Digital Control & Monitoring, Information Systems, Industrial and Building Automation.

View Chart
